Features
Four outputs independently Charge 1-4 cell Lithium Polymer batteries
Automatically detects number of cells on each output-no switch to set "Constant Current/Constant Voltage" Charge method
Each output features push-button START/STOP control, three-hour safety timer and dial to set battery capacity from 300mAh-3000mAh
Audio and tri-color LEDs provide warnings for improper input voltage and output reverse polarity
Built-in cooling fan
Reverse polarity and current overload protection on input

Specs
Input Voltage: 12-15V DC
Number of Outputs: 4
Input Connectors: Alligator clips, hard-wired directly to charger
Case Size: 8.2" x 1.5" x 5" (208x38x126mm) Weight: 21.8oz (617g)
Battery Type: 1-4 (3.7-14.8V) Lithium Polymer cells only
Charge Control: Push-button
Charge Termination: "Constant Current/Constant Voltage"
Battery Capacity Range: 300-3000mAh (for batteries larger than 3000mAh, full Charge time will exceed one hour)
Fast Charge Current: 300mA-3.0A
Status Indicators: Tri-colored LED and audible buzzer
Charge Output Jacks: Banana jacks
Safety Timer: 3-hour maximum Charge time
Fuse: 20A replaceable auto type spade fuse

Note: This charger requires either an external 12VDC Power Supply or Battery, it does NOT plug in to 110V AC power
