Features
Charges 1-14 cell NiMH and NiCd cells and 1-6 cell LiPo, Li-Ion and LiFe (3.6, 3.7 or 3.3V cells)
Peak detection technology for NiCd and NiMH batteries, and constant current/constant voltage technology for lithiums and lead-acid batteries
Ideal for radio batteries and with charge currents adjustable from 100mA to 5 amps (limited to 1C for lithiums) it can also handle large power packs
Built-in balancing for up to 6S LiPo, Li-Ion or LiFe (A123) cells with FlightPower and ElectriFly adapters
Discharge cutoff voltage can be adjusted for NiCd/MH, and is fixed for lithiums and lead-acid batteries
NiCd and NiMH trickle current is automatically set at 1/20th of the fast charge current setting
Reversed LCD with backlight plus a 0-45° adjustable view angle clearly displays input and output volts, peak volts, individual lithium cell voltages, average discharge volts, charge and discharge capacity, currents and time, error messages and more
Touchpad controls and super-simple programming make for simplicity and reliability
Safety features include fast charge safety timer, current overload and reverse polarity protection

Specs
AC Input Voltage: 110V 60Hz - 240V 50Hz (detachable AC cord)
DC Input: 11-15.0V DC, with large alligator clips
Number of Outputs: One, banana jacks
Battery Types, # cells: 1-14 NiCd, NiMH; 1-6 LiPo, Li-Ion, or LiFe (3.6, 3.7 or 3.3V cells); 2-12V Pb (2V per cell)
Fast Charge Current: 0.1-5.0A (1C maximum for lithiums); 63W max DC, 50W max AC
Fast Charge Termination: Peak detection NiCd, NiMH, cc/cv for Pb and lithiums
Trickle Current (NiCd/MH only): Chg current / 20
Peak Sensitivity (NiCd/MH only): 8mV NiCd, 5mV NiMH
Peak Delay at Start (NiCd/MH only): 3 minutes
Fast Charge Safety Timer: NiCd/MH 1.5 hours, lithiums 3 hours, or turn off
Lithium Balancing Accuracy: 5mV per cell
Lithium Balancing Connector: FlightPower and ElectriFly adapters included
Lithium Max. Node Current: 300mA
Discharge Current: 0.1-1.0A (5W max)
Discharge Cutoff Voltage: NiCd, NiMH 0.1-16.8V; LiPo, Li-Ion 3.0V per cell; LiFe 2.5V per cell; Pb 1.8V per cell
Cycle Count (NiCd, NiMH only): 1-5 cycles
Battery Memories: One
Programming Controls: Membrane touchpad, 4 buttons
Display Type: 2x16 reversed LCD w/backlight and adjustable angle
Audible Indicators: Beeper
Case Material: Aluminum and ABS plastic
Safety Devices: Solid-state reverse polarity and overload
Case Size: 5.9 x 6.0 x 2.3 in (150 x 153 x 58mm)
Weight: 23.8oz (675g, w/o AC power cord)
