Motor Diameter: 1.38" (35mm)
Motor Length: 1.18" (30mm)
Shaft Diameter: .16" (4mm)
Shaft Length: .65" (16.5mm)
Lead Length: 3" (76mm)
Connectors: Bullet type, .14" (3.5mm) diameter
Max. Constant Current: 30A
Max. Surge Current: 35A
Max. Constant Watts: 333W
Max. Burst Watts: 390W
No Load Current: 1.2A
Input Voltage: 7.4 - 11.1V (2 - 3S LiPo)
RPM/V (kV Rating): 1250
Weight: 2.5oz (71g)
Suggested Propeller Size: 10x4.5 - 10x7 electric
